A21 LED pixel light is the first kind light control product, which is excellent in brightness consistency from far to the nearest person. Its appearance is exquisite. and use to indoor and outdoor general. The lamp transmission signal adopts the standard DMX512 control technology with the automatic code function, 16bit Dimming,0-65536 level grayscale precision gamma correction algorithm, color change fine and smooth,.It is suitable for various external contours and apply to the outdoor advertising screen of high-rise buildings, which can realize dimming, RGB and video playback and it is suitable for ambient temperature. The led pixel light lifetime is more than 35000 hours at -35°C~+55°C
Lamp body is made by Die-casting Aluminum alloy and anti-fire ABS;5*1.5mm² weather
resistant flat connect;Light guide system is clear PC cover; Light control accessories are PMMA len.
Surface Treatment : The lamp body is finished by one -time molding. The lamp lanterns external parts of mechanical and chemical anti-corrosion treatment and Akesu
Nobel ultraviolet resistant polyester powder, outdoor grade spraying or oxidation treatment import weathering PU sealant 。
Electric Appliance: Built-in electronic driver with over temperature overload protection。
Installation :Outlet wire 0.15m is anti-fire flat cable wire 5x1.5m㎡（DMX Dimming、RGB version)。
Outlet wire 0.15m is anti-fire flat cable wire is anti-fire flat cable wire 2x1.5m㎡(ON/OFF version )
The integrated installation:10Dots/Meter/120Dots/12M/PC and various installation methods:(Fixed Clip Installation or Aluminum Alloy Installation）。
Option : Customed outlet wire length or lamp body color。
